10 Most Common Defects

Information & Frequently Asked Questions

  1. Damp to External Walls

Commonly caused by the failure of the Damp Proof Course (DPC) or bridging the DPC by increasing external ground levels (usually 150mm above ground level).

  1. Failed Gutters & Downpipes

The most common failure points of rainwater goods are at the corners of guttering, joins and rainwater outlets. A blocked gutter can cause damp issues / failure of masonry and can lead to structural issues if left long enough. The most common guttering defects are blocked rainwater outlets, corroded gutters, cracked guttering and failure of rainwater goods below ground level.

  1. Roof – Structural Failure

In regards to roof structure, a whole host of defects can occur. These include woodworm, wet & dry rot, roof spread and sagging of purlins (a horizontal beam along the length of a roof, resting on principal beams and supporting the common rafters or boards).

  1. Roof – Coverings Failure

One of the most common failures of slate roof coverings are the nails holding the tiles to the batons corroding and causing the slates to move and slip out of place. Where concrete or clay tiles are used the tiles can crack and spool, leading to water ingress and structural problems due to rotting roof structures.

  1. Structural Alterations

A lot of residential defects are caused by alterations to the original structure, where proper materials or expert design haven’t been used. For example, if a load bearing wall is removed, a proper steel structure design must be used to ensure the load can be taken safely and without fault.

  1. Condensation

Condensation dampness usually occurs when there is a high ‘relative humidity’ level, a measure of moisture content within the air.  As the relative humidity increases past 100% moisture droplets form as condensation on cold surfaces. Many factors could cause the relative humidity to rise including a lack of proper ventilation, the number of building occupants, drying clothes internally or cooking.

  1. Condensation in Windows and Doors

The most common issue with uPVC doors and windows is condensation within the sealed double glazed unit, due to the degradation of the seals.

  1. Defective Flat Roof

Older flat roof’s are generally constructed with a mineral felt or asphalt covering. These types of coverings generally have a life span of 10-20 years and therefore commonly found to be defective. Newer coverings, such as GRP (Glass Reinforced Plastic) can have a life span of 40 years + if maintained correctly. UV rays can cause degradation to the outer surfaces and there can be weathering and cracking to the various layers. Other defects can include faulted flashings and ponding – meaning that the roof does not drain effectively.

  1. Structural Movement

Cracking, bowing or leaning walls and sticking doors or windows are all indicators of structural movement in your house. The main types of structural movement are subsidence, heave, settlement, thermal movement and seasonal movement.

  1. Eroded Pointing

Pointing to masonry walls used to be a lime based mix on older properties, however, on newer properties a harder cement based mix is used. Pointing generally occurs to brickwork exposed to the elements and weathered over time, or due to failed guttering.

Having a problem with anything in the list?

The team at ESQ Associates are here to assist you with any query you may have.

Call us on our office number or drop us an email and one of our friendly staff will get back to you as soon as possible.

Need help? Call on:

07593 216 092

Building Survey F.A.Q.

We get asked questions all the time and we try and answer every single one. Here we have compiled a list of our most frequently asked questions. However, if your subject isn't listed, please, ask us a question.
Cracks in Buildings

Cracks are the most common type of problem in any type of building. However, most people don’t know whether they should be concerned. Click here to read more

Damp in my House

Damp refers to the presence of moisture, water, and condensation being present within a property. Click here to read more

Gutter Problems

Proper maintenance on the gutters at your property is perhaps the most important thing you can do to prevent water penetration and damage to your home. Click here to read more

Lime Mortar Issues

Lime mortar is comprised of lime (hydraulic, or non hydraulic), water and an aggregate such as sand. Nowadays, it is generally used in conservation work or the construction of new buildings using traditional methods - generally for aesthetic reasons or as a planning requirement. Click here to read more

Timber

Timber is an excellent building material as it is easy to work with, a natural insulator and offers a quick build time, along with a whole other long list of advantageous features. However, timber is susceptible to a few defects that brick & block or concrete construction isn’t. Click here to read more
